STAN Tool for the identification of the frequency response H0 (jωs)

In STAN Tool, to obtain a pole-zero map, a transfer function H0(s) is processed after identifying the frequency response H0(jωS). An automatic algorithm that searches for the best possible order of the function has been developed in STAN Tool. This algorithm automatically searches for the transfer function’s appropriate order with the phase tolerance parameter’s aid facilitating the identification process. This phase tolerance represents the maximum phase error permitted between the frequency response H0(jωs) and the transfer function H0(s).

The transfer function H0(s) associated to H0(jωS) will be obtained by using one of the two methods available in STAN Tool:

  • SISO
  • DACWIN
    Figure: Resume identification using STAN Tool to obtain the pole-zero map
